Facilities List

(2) MORI SEIKI – CNC TURNING CENTERS   – SL-25

  • Max. Swing        15.5”
  • Chuck Size        10”
  • Shaft Length        21”
  • Bar Capacity        2.4”
  • Drive     20/15 HP
MORI SEIKI – CNC TURNING CENTERS   – SL-25

MORI SEIKI – CNC TURNING CENTERS – SL-25

(2) MORI SEIKI    –   CNC TURNING CENTERS   – SL- 403

  • Max. Swing        24.0”
  • Chuck Size        15”
  • Shaft Length        34”
  • Bar Capacity        5.0”
  • Drive     40/30 HP
MORI SEIKI    -   CNC TURNING CENTERS   – SL- 403

MORI SEIKI – CNC TURNING CENTERS – SL- 403

(1) HITACHI SEIKI – CNC TURNING  CENTERS   – Turn 20

  • Max. Swing  12.0”
  • Chuck Size  8.0”
  • Shaft Length  24”
  • Bar Capacity  1-3/4”
  • Spindle Drive Motor  15/10
HITACHI SEIKI – CNC TURNING  CENTERS   – Turn 20

HITACHI SEIKI – CNC TURNING CENTERS – Turn 20

(1) MORI SEIKI – CNC TURNING CENTER – NL2500/700

  • Max. Swing 14.0”
  • Chuck Size  12”
  • Shaft Length  27.7”
  • Bar Capacity  3.1”
  • Spindle Drive Motor  20/15
MORI SEIKI – CNC TURNING CENTER – NL2500/700

MORI SEIKI – CNC TURNING CENTER – NL2500/700

(1) MORI SEIKI – CNC TURNING CENTERS   – SL-25

  • Max. Swing        12.0”
  • Chuck Size        8.0”
  • Shaft Length        32”
  • Bar Capacity        1-3/4”
  • Drive     15 HP
MORI SEIKI - CNC TURNING CENTERS   – SL-25

MORI SEIKI – CNC TURNING CENTERS – SL-25

(1) HITACHI SEIKI – CNC TURNING CENTERS   – 4NE-600

  • Max. Swing        12.0”
  • Chuck Size        12.0”
  • Shaft Length        24”
  • Bar Capacity        1-3/4”
  • Drive     10 HP
HITACHI SEIKI – CNC TURNING CENTERS   – 4NE-600

HITACHI SEIKI – CNC TURNING CENTERS – 4NE-600

(1) MORI SEIKI – HORIZONTAL MACHINING CENTER NH5000 DCG/50   50 CT

  • Pallet Size 20” x 20”
  • X-Axis        28.7”
  • Y-Axis        28.7”
  • Z-Axis        33.5”
  • 54 Tool Magazine
  • Drive    40/30 HP
MORI SEIKI – HORIZONTAL MACHINING CENTER NH5000 DCG/50   50 CT

MORI SEIKI – HORIZONTAL MACHINING CENTER NH5000 DCG/50 50 CT

 (1) MAZAK – HORIZONTAL MACHINING CENTER – FH 6800

  • Pallet Size 27” x 27”
  • X-Axis        41.3”
  • Y-Axis        31.5”
  • Z-Axis        34.5”
  • 80 Tool Magazine        50 CT
  • Drive     40/30 HP
MAZAK – HORIZONTAL MACHINING CENTER – FH 6800

MAZAK – HORIZONTAL MACHINING CENTER – FH 6800

(1) MORI SEIKI – CNC VERTICAL MACHINING CENTER –  NV5000B WITH A NIKKEN CNC180 4TH AXIS

  • X-Axis        40”
  • Y-Axis        20”
  • Z-Axis        20”
  • 30 Tool Magazine
  • Drive     18 HP
  • 12” work Dia. 360 Deg. Rotation
MORI SEIKI – CNC VERTICAL MACHINING CENTER -  NV5000B WITH A NIKKEN CNC180 4TH AXIS

MORI SEIKI – CNC VERTICAL MACHINING CENTER – NV5000B WITH A NIKKEN CNC180 4TH AXIS

(1) KONDIA – CNC VERTICAL MACHINING CENTER – B1000

  • X-Axis        39”
  • Y-Axis        16”
  • Z-Axis        20”
  • 18 Tool Magazine        40 CT
  • Drive     10 HP
Kondia - CNC Vertical Machining Center - B1000

Kondia – CNC Vertical Machining Center – B1000

(1) HITACHI SEIKI -HORIZONTAL MACHINING CENTER – HC500

  • Pallet Size   19” x 19”
  • X-Axis        30”
  • Y-Axis        24”
  • Z-Axis        20”
  • 40 Tool Magazine        50 CAT
  • Drive     15 HP
HITACHI SEIKI -HORIZONTAL MACHINING CENTER – HC500

HITACHI SEIKI -HORIZONTAL MACHINING CENTER – HC500

(1)MASTER – CUT -S460 HB PRODUCTION SAW

  • Stock Dia. Max        19″
  • Self Feed
MASTER – CUT -S460 HB PRODUCTION SAW

MASTER – CUT -S460 HB PRODUCTION SAW

INSPECTION EQUIPMENT:

SHEFFIELD DISCOVERY II

C.M.M. DCC

With – PC – DMIS  2014

Measuring Range 30” x 40” x 24”

First piece and in process inspection reports available per customer request.

SPC capability studies and charting per customer request.

sheffield-discovery-II



ENGINEERING

Powered by SURFCAM

Vertical Machining   –   2D

Turning Centers        –   2D
